PFC Parallel Flange Channel dimension is also popular in South Africa
parallel flange steel channel sizes are an essential load-bearing profile Typically used as columns or as support for floor joists, floor beams, portal frames, and trailer frames. the material of mild steel is easy to weld, cut, form, and machine with the proper equipment. channel parallel flange dimensions such as 100×50 and 150×75 are huge volumes of demand in the market.
weight | Actual, Theoretical |
---|---|
Tolerance | 0-15% |
Grade | A36, Q235, Q355, S235JR, SS400 |
Length | 12m, 5.8m, 6m |
Loading port | Xingang port |
Payment | LC at sight, TT |
HS tariff code | 721610, 721631, 722870 |
Origin | China |
Parallel Flange Channel(PFC)AU | |||||
size | h | b | s | t | weight |
mm | mm | mm | mm | mm | (kg/m) |
75PFC | 75.00 | 40.00 | 3.80 | 6.10 | 5.90 |
100PFC | 100.00 | 50.00 | 4.20 | 6.70 | 8.31 |
125PFC | 125.00 | 65.00 | 4.70 | 7.50 | 11.90 |
150PFC | 150.00 | 75.00 | 6.00 | 9.50 | 17.70 |
180PFC | 180.00 | 75.00 | 6.00 | 11.00 | 20.90 |
200PFC | 200.00 | 75.00 | 6.00 | 12.00 | 22.90 |
Parallel Flange Channel(PFC)BS | |||||
size | h | b | s | t | weight |
mm | mm | mm | mm | mm | (kg/m) |
100PFC | 100 | 50 | 5 | 8.5 | 10.2 |
125PFC | 125 | 65 | 5.5 | 9.5 | 14.8 |
150PFC | 150 | 75 | 5.5 | 10 | 17.9 |
